Model: EA175V: Type: Air-cooled, 4-cycle, single cylinder, OHC, vertical PTO shaft, gasoline engine. Bore x Stroke mm(in.) 68x48(2.68x1.89) Piston displacement. Start Right Here Find appliance parts, lawn & garden equipment parts, heating & cooling parts and more from the top brands in the industry here. Click on Shop Parts, or select the kind of product you're working with on the left and we'll help you find the right part. Ariens genuine OEM parts provide peace of mind and the confidence of knowing these parts were specifically designed for an exact fit, optimal performance and safety. Robin/Subaru EA175V75080 Exploded View parts lookup by model. Complete exploded views of all the major manufacturers. It is EASY and FREE. The EA175V engine was produced until 2017 under the brand Subaru Industrial Power Products, which was previously referred to as Robin, Subaru-Robin and Wisconsin Robin. This engine used for lawn mowers and garden applications including pressure washers, walk behind string trimmers, aerators and lawn vacs.
The Subaru-Robin EA175V is a 0.2 L (174 cc, 10.62 cu·in) natural aspirated single-cylinder four-stroke air-cooled internal combustion small gasoline engine with a vertical shaft, manufactured by the Industrial Products division of Subaru Corporation for general-purpose applications.
The EA175V engine was produced until 2017 under the brand Subaru Industrial Power Products, which was previously referred to as Robin, Subaru-Robin and Wisconsin Robin. This engine used for lawn mowers and garden applications including pressure washers, walk behind string trimmers, aerators and lawn vacs.
The EA175V engine has a single cylinder, overhead camshaft (OHC) design, vertical shaft, and recoil starter. This engine used float type carburetor, capacitance discharge type ignition system, centrifugal flyweight type governor, mechanical splash type lubricating system and forced-air cooling system. The engine is fitted with a foam air cleaner (paper air cleaner was available as an option). The EA175V is equipped with 0.6 L (0.16 US. gal. 0.13 Imp. gal.) fuel tank.
The Subaru-Robin EA175V engine produced 4.5 PS (3.4 kW; 4.5 HP) at 3,600 rpm of maximum horsepower and 10 N·m (1 kg·m, 7.4 ft·lb) at 2,500 rpm of peak torque.
General information
Subaru Ea175v Carb
| Engine Specifications | |
| Engine model | EA175V |
| Engine type | 4-stroke, OHC, single-cylinder |
| Displacement | 174 cm2, (10.62 cu·in) |
| Max. horsepower | 4.5 PS (3.4 kW; 4.5 HP) at 3,600 rpm |
| Max. torque | 10.0 N·m (1.0 kg·m, 7.4 ft·lb) at 2,500 rpm |
| Cooling system | Forced air |
| Air cleaner | Foam (Optional Paper) |
| Lubricating system | Splash type |
| Ignition system | Сapacitance discharge type |
| Fuel system | Float type carburetor |
| Fuel consumption | 395 g/kWh |
| Fuel tank capacity | 0.6 L (0.16 US. gal. 0.13 Imp. gal.) |
| Fuel used | Unleaded gasoline (octane number 86 or higher) |
| Starting system | Recoil starter |
| Stoping system | Ignition primary circuit ground |
| Governor | Centrifugal flyweight type |
| PTO shaft rotation | Anticlockwise（see from the direction of the crankshaft housing) |
| Dimensions (L x W X H) | 397 x 360 x 268 mm (15.6 x 14.2 x 10.6 in) |
| Dry weight | 13.0 kg (28.7 lbs) |
Subaru Lawn Mower Ea175v Rear Axle Bearings
Cylinder Block and Head
Cylinder bore and piston stroke are 68.0 mm (2.68 in) and 48.0 mm (1.89 in), respectively. Compression ratio rating is 9.0:1. The Subaru EA175V used a cast-iron cylinder liner with heavy-duty piston rings, forged high-carbon steel crankshaft with ball bearing supporting system and hardened steel rocker arms with precision tappet adjusters. The piston is fitted with two compression rings and a single oil ring.
| Cylinder block | |
| Compression ratio: | 9.0:1 |
| Cylinder bore: | 68.0 mm (2.68 in) |
| Piston stroke: | 48.0 mm (1.89 in) |
| Cylinder internal diameter (standard): | 68.000-68.020 mm (2.6772-2.6779 in) |
| Piston skirt outer diameter (standard): | 67.989-67.971 mm (2.6767-2.676 in) |
| Number of piston rings (compression / oil): | 2/1 |
| Connecting rod big end diameter (standard): | 30.000-30.018 mm (1.1811-1.1818 in) |
| Connecting rod small end diameter (standard): | 16.005-16.021 mm (0.6301-0.6307 in) |
| Piston pin diameter: | 13.994-14.000 mm (0.5509-0.5512 in) |
| Top ring side clearance: | 0.04-0.08 mm (0.0016-0.0031 in) |
| Second ring side clearance: | 0.04-0.08 mm (0.0016-0.0031 in) |
| Top ring end gap: | 0.13-0.28 mm (0.0051-0.011 in) |
| Second ring end gap: | 0.20-0.40 mm (0.0079-0.0157 in) |
| Top ring width: | 2.50-2.70 mm (0.0984-0.1063 in) |
| Second ring width: | 2.60-2.80 mm (0.1024-0.1102 in) |
| Crankpin journal diameter: | 29.969-29.981 mm (1.1799-1.1804 in) |
| Crankshaft center distance: | 24.0 mm (0.945 in) |
| Cylinder head | |
| Valve arrangement: | OHC, chain driven |
| Valves:: | 2 |
| Intake valve steam diameter: | 5.440-5.455 mm (0.2142-0.2148 in) |
| Exhaust valve steam diameter: | 5.430-5.445 mm (0.2138-0.2144 in) |
| Intake valve spring free length: | 30.50 mm (1.2008 in) |
| Exhaust valve spring free length: | 30.50 mm (1.2008 in) |
| Intake camshaft lobe height: | 23.98 mm (0.9441 in) |
| Exhaust camshaft lobe height: | 27.88 mm (1.0976 in) |
| Camshaft journal diameter : | 9.000-9.040 mm (0.3543-0.3559 in) |
Tightening torque settings:
- Connecting rod bolt: 13 Nm; 1.33 kg·m; 9.59 ft·lb
- Cylinder head bolt: 26 Nm; 2.65 kg·m; 19.19 ft·lb
- Flywheel nut: 52 Nm; 5.3 kg·m; 38.38 ft·lb
- Crankcase cover bolt: 10 Nm; 1.02 kg·m; 7.38 ft·lb
- Value locking nut: 6 Nm; 0.61 kg·m; 4.43 ft·lb
- Oil drain bolt: 22 Nm; 2.24 kg·m; 16.24 ft·lb
Service Data
NGK:Subaru Lawn Mower Ea175v Rear Axle Assembly
CHAMPION:TORCH:
The valve clearance is 0.10-0.15 mm (0.0039-0.0059 in) for intake valves and 0.15-0.20 mm (0.0059-0.0079 in) for exhaust valves. Standard cylinder compression is 1.15 MPa at 1200 rpm.
| Engine | |
| Maximum speed: | 3,800±100 rpm |
| Cylinder compression: | 1.15 MPa at 1200 rpm |
| Valve clearance | |
| Intake valve clearance: | 0.10-0.15 mm (0.0039-0.0059 in) |
| Exhaust valve clearance: | 0.15-0.20 mm (0.0059-0.0079 in) |
| Oil system | |
| Lubrication system: | Splash type |
| Oil type: | 5W-30, 10W-30 |
| Recommended oil: | 4-stroke engine oil, API service classification SE |
| Oil capacity: | 0.6 L (0.63 US. qt, 0.53 Imp. qt.) |
| Fuel system | |
| Type: | Float type carburetor |
| Ignition system | |
| Type: | Сapacitance discharge type |
| Spark plug: | NGK: BPR6HS or BPR7HS CHAMPION: RL82YC or RL87YC TORCH: E7RTC or E6RTC |
| Spark plug gap: | 0.7-0.8 mm (0.0276-0.0276 in) |
| Spark plug torque: | 22 N·m (2.2 kg·m, 16.2 ft·lb) |
